Automatic Keyway Milling Machine
(PSA Series)
The Automatic Keyway Milling Machine (PSA Series) is designed for producing precise keyways on a wide range of workpieces. The machine uses a servo mechanism for controlled depth of cut and consistent keyway machining in high-production applications.
A Programmable Logic Controller (PLC) provides automatic feed with variable depth of cut according to the programmed stroke requirement. Once the required final depth is achieved, the machine automatically stops, provides a buzzer indication and returns the spindle to its home position.
- The overall Machine Operation handled with Programmable Logic Controller (PLC)
- Easily achieve P9 Tolerance
- Depth of cut can be controlled by SERVO Mechanism
- Touch Screen HMI provides smooth operation and user friendly job settings
- Self-centering vice is used for holding the shaft or job
- Very easy setting of length for making Key-way
- Silent working & smooth cutting of key-way
- Easy and operator-friendly operation
- Very easy operating compared to lathe machine or conventional milling machine
- Low-maintenance machine design
- Tablet Die-punch (Pharmaceutical) industry
- Gearbox, Submersible Pump & Electric Motor Manufacturers
- Textile, Printing & Packaging Machinery Manufacturers
- Engineering Job Works
- Machine Tool Industry
Specifications
PSA-1
PSA-2
PSA-3
Max. Spindle Speed :
2460 RPM
Upto 2460 RPM
Upto 2460 RPM
Table Feed :
0-600 mm / Min
0-600 mm / Min
0-600 mm / Min
Clamping Capacity :
15 mm - 70 mm
20 mm - 85 mm
25 mm - 95 mm
Max. Length of Key-Way :
Upto 150 mm
Upto 200 mm
Upto 200 mm
Key-Way Size :
3 mm - 12 mm
3 mm - 16 mm
3 mm - 20 mm
Depth of Cut :
0.010 to 0.300 mm
0.010 to 0.300 mm
0.010 to 0.300 mm
Control Type :
Automatic (PLC Control)
Automatic (PLC Control)
Automatic (PLC Control)
Control Mechanism :
Mechanical - CAM with Spindle Servo
Mechanical - CAM with Spindle Servo
Mechanical - CAM with Spindle Servo
Spindle Operation :
Lead Screw Mechanism
Lead Screw Mechanism
Lead Screw Mechanism
Spindle Control :
Switch-gear Control
VFD with PLC Control
VFD with PLC Control
Table Control :
VFD with PLC Control
VFD with PLC Control
VFD with PLC Control
Standard Collet :
ER-20
ER-25
ER-32
Power Supply :
3-PH / 440VAC
3-PH / 440VAC
3-PH / 440VAC
